|TOOLING:||4 To 5 Times Greater Tool Life.||WEIGHT:||Easier Handling Saves Energy And Time.|
|CORROSION RESISTANT:||A Wide Variety Of Chemical Treatments Exists For Corrosion Protection, Alteration Of Surface Appearance, And To Provide A Base For Painting. Basic Engineering Precautions Averts Galvanic Corrosion.||STABILITY:||No Stress Relief After Machining; No Warps And Is Dent Resistant.|
|NONMAGNETIC:||Good For Electrical And Computer Applications.||DAMPING:||Absorbs Vibration For Longer Life, While Retaining Dimensional Stability.|
|Thermal Conductivity::||76.9Wm-1k-1||Electrical Resistivity::||92nΩm|
|Modulus Of Elasticity::||45 X 109Pa||Density:||1.78|
XIAN YUECHEN METAL PRODUCTS CO. LTD. (XYMCO) produces the standard size magnesium CNC engraving plate / sheet as follows:
1.50 x 610 x 914mm;
1.75 x 610 x 914mm;
2.00 x 610 x 914mm;
3.00 x 610 x 914mm;
4.00 x 610 x 914mm;
4.50 x 610 x 914mm;
5.00 x 610 x 914mm;
6.00 x 610 x 914mm;
7.00 x 610 x 914mm;
10.0 x 610 x 914mm.
1.50 x 500 x 1000mm;
1.75 x 500 x 1000mm;
2.00 x 500 x 1000mm;
3.00 x 500 x 1000mm;
4.00 x 500 x 1000mm;
4.50 x 500 x 1000mm;
5.00 x 500 x 1000mm;
6.00 x 500 x 1000mm;
7.00 x 500 x 1000mm;
10.0 x 500 x 1000mm.
XYMCO always maintains enough quantity magnesium CNC engraving plate / sheet in stock to make sure fast delivery, competitive price and excellent quality.
Why Magnesium Plate?
Magnesium CNC engraving plate has good carving processing performance. Because of its outstanding characteristics of magnesium plate engraving of low density, high specific stiffness, good damping property, environment friendly and no pollution, Recyclable good performance, known as the twenty-first Century green metal structure material.
The magnesium CNC engraving plate and mechanical processing of parts, in national defense, aerospace, electronic communication, rail transportation, medical equipment, printing plate, magnesium board carving mold and other fields, and has wide application prospect.
Magnesium CNC engraving plate as a kind of excellent metal material processing machinery and carving, has the following characteristics:
Cutting energy consumption with magnesium CNC engraving plate into 1, then 2.3 to 1.8 brass, aluminum, iron is 3.5; the cutting inertia is small it magnesium plate, can realize high speed cutting.
Magnesium CNC engraving plate, dimensional stability, not easy to change with temperature.
Non magnetic metal magnesium, magnesium plate shielding electromagnetic, strong anti-interference ability.
Magnesium has excellent damping properties, good damping.
Engraving magnesium board high specific stiffness. Magnesium the proportion of small, light weight.
Magnesium rich reserves of resources, recycling use.
Magnesium is widely exists in the nature, the magnesium CNC engraving plate can be naturally decomposed into magnesium salt, no harm to soil and water.
Magnesium CNC engraving plate adopts the carving process of high speed cutting has the following characteristics:
The feed speed engraving cutter can be improved more than 6 times; material removal rate can be increased by 5-6 times;
Magnesium aluminum plate surface roughness is greatly increased, up to 10 μ m
Generally, carving cutting resistance magnesium plate to reduce the 1/3;
Magnesium CNC engraving plate after hot deformation is low, can limit the work hardening;
Engraving tool durability increased nearly one times;
Magnesium CNC engraving plate processing time can be significantly reduced, directly led to reduced processing cost;
Cutting resistance magnesium plate of small, good thermal conductivity, heat quickly, so the cutting speed is very fast, very few sticky knives. Engraving and cutting tool life is long, and shortens the required tool replacement in the carving process downtime.
The chip formation in magnesium board carving process, associated with the shape of parts, alloy composition, feed speed and other factors. Because magnesium CNC engraving plate cutting, the chip integrity, continuous, general situation next finishing can meet the requirements of the carving surface roughness.
Mn: 0.20 – 1.0%
Coefficient of thermal expansion: 26.8 x 10-6K-1
Specific heat: 1040 Jkg-1k-1
Thermal conductivity: 76.9Wm-1k-1
Electrical resistivity: 92nΩm
Modulus of elasticity: 45 x 109Pa
Poissons ratio: 0.35
Melting range: 566 - 632°C
No thermal treatment is available for increasing the strength of this alloy after fabrication.
|Alloy and Temper||Thickness (mm)||
0.2% offset (MPa)
In 5.65 √A (%)
|AZ31B-O||0.5 – 1.5||125||221||10|
|1.5 – 6.3||105||221||9|
|6.3 - 75||105||221||8|
|AZ31B-H24||0.5 – 6.3||200||269||5|
|9.5 – 12.7||165||255||8|
|12.7 - 25||152||248||8|
|50 - 80||124||234||7|
|AZ31B-H26||6.3 - 10||186||269||6|
|10 – 12.5||179||262||6|
|12.5 - 20||172||255||5|
|20 – 25||159||255||5|
|25 - 40||152||241||5|
|40 - 50||148||241||5|
The sheet and plate shall conform to the tensile requirements in above Table unless other agreement is made between seller and purchaser. Mechanical Properties for sizes and tempers not shown in above Table shall be as agreed upon by seller and purchaser.
O temper: 67 Rockwell E
H24 temper: 83 Rockwell E
Excellent weldability with gas shielded arc using AZ61A (preferred) or AZ92A filler rod; post weld stress relief is required to prevent stress corrosion cracking. Resistance welding is excellent.
AZ31B, like all magnesium alloy sheet and plate, machines faster than any other metal. Providing the geometry of the part allows, the limiting factor is the power and speed of the machine rather than the quality of the tool material. The power required per cubic centimeter of metal removed varies from 9 to 14 watts per minute depending on machining operation.
Weight for weight, AZ31B-H24 has proven to be superior to competitive materials in its resistance to denting at moderate energy levels.
Dent Resistance of 1mm Gauge Sheet (Dent depth in mm from 25mm spherical redius indentor on 350mm span)
|Impact Energy 0.34 J||Impact Energy 0.62 J||Impact Energy 1.25 J|
6061 – T6
3003 – H14
5052 – H34
2024 – T6
SAE 1010 Mild Steel
All the normal chromating, anodizing, plating, and finishing treatment are readily applicable. AZ31B also responds well to plasma electrolytic oxidation finishing.
Continuous exposure for 2.5 years.
Mild steel 0.323mg.cm-2d-1
Mild steel 0.055mg.cm-2d-1
Mild steel 0.032mg.cm-2d-1
XIAN YUECHEN METAL PRODUCTS CO., LTD. (XYMCO) is one of the leading manufacturer of magnesium alloy products located in Xincheng Hi-Tech Industry Estate, Xi’an, Shaanxi, China, who is specialized in the development, manufacture and supply of magnesium alloy products worldwide included magnesium tooling plate, magnesium alloy plate, magnesium alloy sheet, magnesium alloy slab, magnesium alloy bar, magnesium alloy billet, magnesium alloy rod, magnesium alloy tube, magnesium alloy pipe, magnesium alloy profile, magnesium welding wire, magnesium alloy extrusion, magnesium alloy stamping, magnesium alloy casting, magnesium alloy forging and semi - fabricated component according to customer’s design.
We comply with the specifications:
GB5153-03, GB5154-04, AMS4377G, ASTM B90/B90M-15, MIL-DTL 32333, MIL-T-38749, QQ-M-44B, ASTM B107/B107M-13 and ASTM B91-97
Material grades: AZ31B, AZ61A, AZ80A, AZ91D, AZ41M, ZK60, AM50, AM60, ZM21, MIA, ME20M, EQ21, WE43, WE54, ZE41, etc.
Our main products and capabilities are as follows:
1. Magnesium tooling plate: Max. Thickness: 300mm; Max. Width: 2000mm; Max. Length: 6000mm
2. Magnesium alloy cast slab: Max. Size: 400 x 1000 x 3000mm
3. Magnesium alloy sheet: Min. Thickness: 0.5mm; Max. Width: 600mm; Max. Length: 2000mm
4. Magnesium cast billet: Min. Diameter 90mm; Max. Diameter: 600mm; Max. Length: 6000mm
5. Magnesium alloy extruded wire: Dia.1.0mm – 8.0mm in spool.
6. Magnesium alloy extruded rod: Min. Dia. 8mm; Max. Diameter: 450mm; Max. Length: 3000mm
7. Magnesium extrusions:
Round tube: Max. OD600mmx thickness 125mm
Square tube: 430 x 430mm
Flat bar: 920 x 160mm
U-Shape: 800 x 300mm
Rectangular: 700 x 200mm
8. Magnesium-Lithium Alloy rod, sheet, plate and tube.
XIAN YUECHEN METAL PRODUCTS CO., LTD. (XYMCO) is able to mass produce LZ91, LA91, LA141, MA18 and MA21 magnesium lithium alloys in the form of rectangular or round shape ingot by vacuum melting techniques, and mass produce MgLi wrought alloys and its products of magnesium lithium alloy slab, magnesium lithium alloy bock, magnesium lithium alloy plate, magnesium lithium alloy sheet, magnesium lithium alloy foil, magnesium lithium alloy strip, magnesium lithium alloy coil, magnesium lithium alloy billet, magnesium lithium alloy rod, magnesium lithium alloy bar, magnesium lithium alloy tube, magnesium lithium alloy pipe, magnesium lithium alloy wire, magnesium lithium alloy profile by casting, forging, extrusion and hot rolling process. XYMCO also produces the customized sizes (non standard sizes) magnesium lithium alloy materials and its products according to customers’ requirements.
NPFC - MIL-M-46130 Magnesium-Lihium Alloy Plate, sheet and forgings (LA141A, LS141A and LZ145A)
Our products already were exported to USA, Japan, Israel, India, Germany, Iran, Columbia, Italy and UK. Good quality, good price and good delivery.
Looking forward to your enquiry and hope a prosperous cooperation can be established between us.
1. Small order quantity available
2. Professional engineering team and sales team
3. Payment: T/T & Western Union
4. OEM/ODM Supporttable
5. Free samples provided
6. Competitive price and high quality
1. Q: Are you a factory or trading company?
A: We are direct manufacturer located in Xi'an, Shaanxi province, and have our equipment!
2. Q: Are your products customized?
A: Yes,the products in the website are only the common type or the previous types, we can supply the new products according to your requirements or drawings.
3. I do not know how to use your product ?
Do not worry ! We can supply technical guidance together with products.
4. Q: How can I get some samples?
A: Several samples are freely offered for buidling the business long-term relationships and letting our customers believing the quality of our products.
